ProffieOS7 Style Library Phase 3 (Public Access) - Q & A

ProffieOS Fett263 Corner
63

Can I ask if there’s a particular Sound Font that pairs with the Infinity Gauntlet style? I’d love to get that setup on one of my sabers

64

I can’t recall, but I believe there used to be a Thanos font a few years back. I don’t remember who made it though.

65
1 Like
66

ok so i setup my saber with a few of these blade styles before and now i cant get them to work heres the code

Code:
Beskarius.h (65.5 KB)

Error Message:
Compilation error: ‘BASE_COLOR_ARG’ was not declared in this scope

67

Make sure you have ProffieOS 7.15. That error would be from trying to use an older version.

Download 7.15 here:
https://fredrik.hubbe.net/lightsaber/proffieos.html

68

ok tried that but now what config file do i need to use to add my styles

69

Just save your config file into the /config folder of the new ProffieOS folder and be sure to define it in the new ProffieOS.ino.

If you’re unsure, see Step 3 here:

70

That worked thank you i had it working before and then bought a new laptop and started over and for som reson it downloaded the old os instead of the new one

71

You’re welcome, glad to hear.

72

I’ve added several options to the Base Style Accent Overlay section on the Enhancements screen. These can be adjusted via the Time and/or Delay settings, to run full time you’d extend the Time and reduce Delay to 100. They also allow for accompanying overlay sounds if you want.
For more info on Accent Overlays, watch the recommended video at top of library.

You’ll need to refresh page for new scripts.

  • Faulty Blade (NoisySoundLevel) = similar to Faulty Ignition Preon; the size, instability and brightness (to White) of the effect is controlled by sounds playing.
  • Faulty Blade (Random) = similar to Faulty Ignition Preon; size, instability and brightness (to White) is Randomized
  • Glitchy Blade (NoisySoundLevel) = a simple unstable effect; size is controlled by sounds playing.
  • Glitchy Blade (Random) = unstable effect; size is Randomized
1 Like
73

That’s great news. I checked it out and that’s excellent. Thank you for adding the overlays. :slight_smile:

74

You’re welcome

75

Hello! Just wanted to report an issue with the Behemoth Greyscale Blade Style. When trying to access the Style in the Library I receive an error message saying, “Missing Base Style Code for Behemoth (Rolling Wave with Ripple Swing (Scaled Cutting Edge)”.

76

Thanks, I’ll have a look as soon as I get a chance.

77

This has been fixed. You’ll need to refresh the page for the fixes.

78

@Fett263 I’ve been so slammed w work, life, and family that I’m just now catching up. Thanks a ton for adding in the ability to layer bladestyles as well as the other updates. It makes it so much easier to do it as well as teach it. We’re loving what the Style Library has developed into.

Have an awesome holiday season and MTFBWY!

1 Like
79

You’re welcome, glad to hear.

80

Am I missing something, or is the Style Builder not outputting proper options? I’m trying to get 3 variations of Rotoscope into a single style so I can select between them per font, and all 3 show up correctly in the previewer and I can select between them, but when copying the style and putting it into my prop file it just says “Single Style Single Option”.

Style code that was copied is here:

/* copyright Fett263 Rotoscope (Primary Blade) OS7 Style
https://www.fett263.com/fett263-proffieOS7-style-library.html#Rotoscope
OS7.15 v3.210p
Single Style
Style Option
Base Color: BaseColorArg (0)

--Effects Included--
Ignition Effect: Standard Ignition [Color: IgnitionColorArg]
Retraction Effect: Standard Retraction [Color: RetractionColorArg]
Lockup Effect:
0: mainLockMulti0Shape - Begin: Real Clash - Style: Intensity AudioFlicker - End: Full Blade Absorb
[Color: LockupColorArg]
Lightning Block Effect:
0: mainLBMulti0Shape - Begin: Responsive Impact - Style: Strobing AudioFlicker - End: Full Blade Absorb
[Color: LBColorArg]
Drag Effect:
0: mainDragMulti0Shape - Begin: Wipe In - Style: Intensity Sparking Drag - End: Wipe Out
[Color: DragColorArg]
Melt Effect:
0: mainMeltMulti0Shape - Begin: Wipe In - Style: Intensity Melt - End: Wipe Out
[Color: StabColorArg]
Blast Effect: Blast Wave (Random) [Color: BlastColorArg]
Clash Effect: Real Clash V1 [Color: ClashColorArg]
*/
StylePtr<Layers<ColorSelect<IntArg<STYLE_OPTION_ARG,0>,TrInstant,AudioFlicker<Stripes<10000,-2600,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>>,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>>>,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>>,Mix<HoldPeakF<SwingSpeed<250>,Scale<SwingAcceleration<100>,Int<50>,Int<500>>,Scale<SwingAcceleration<>,Int<20000>,Int<10000>>>,RandomFlicker<StripesX<Int<15000>,Scale<HoldPeakF<SwingSpeed<200>,Scale<SwingAcceleration<100>,Int<50>,Int<300>>,Scale<SwingAcceleration<100>,Int<24000>,Int<16000>>>,Int<-3200>,Int<-200>>,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>>,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>,Mix<Int<19276>,Black,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>>>,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>>,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>>,RandomFlicker<Stripes<10000,-2600,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>>,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>>>,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>>>,TransitionEffectL<TrWaveX<RgbArg<BLAST_COLOR_ARG,Rgb<255,255,255>>,Scale<EffectRandomF<EFFECT_BLAST>,Int<100>,Int<400>>,Int<100>,Scale<EffectPosition<EFFECT_BLAST>,Int<100>,Int<400>>,Scale<EffectPosition<EFFECT_BLAST>,Int<28000>,Int<8000>>>,EFFECT_BLAST>,Mix<IsLessThan<ClashImpactF<>,Int<26000>>,TransitionEffectL<TrConcat<TrInstant,AlphaL<RgbArg<CLASH_COLOR_ARG,Rgb<255,255,255>>,Bump<Scale<BladeAngle<>,Scale<BladeAngle<0,16000>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-12000>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<10000>>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-10000>>>,Scale<ClashImpactF<>,Int<12000>,Int<60000>>>>,TrFadeX<Scale<ClashImpactF<>,Int<200>,Int<400>>>>,EFFECT_CLASH>,TransitionEffectL<TrWaveX<RgbArg<CLASH_COLOR_ARG,Rgb<255,255,255>>,Scale<ClashImpactF<>,Int<100>,Int<400>>,Int<100>,Scale<ClashImpactF<>,Int<100>,Int<400>>,Scale<BladeAngle<>,Scale<BladeAngle<0,16000>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-12000>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<10000>>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-10000>>>>,EFFECT_CLASH>>,LockupTrL<TransitionEffect<AlphaL<AlphaMixL<Bump<Scale<BladeAngle<>,Scale<BladeAngle<0,16000>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-12000>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<10000>>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-10000>>>,Scale<SwingSpeed<100>,Int<14000>,Int<22000>>>,AudioFlicker<RgbArg<LOCKUP_COLOR_ARG,Rgb<255,255,255>>,Mix<Int<12000>,Black,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,255,255>>>>,BrownNoiseFlicker<RgbArg<LOCKUP_COLOR_ARG,Rgb<255,255,255>>,Mix<Int<12000>,Black,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,255,255>>>,300>>,Bump<Scale<BladeAngle<>,Scale<BladeAngle<0,16000>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-12000>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<10000>>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-10000>>>,Scale<SwingSpeed<100>,Int<14000>,Int<22000>>>>,AlphaL<AudioFlicker<RgbArg<LOCKUP_COLOR_ARG,Rgb<255,255,255>>,Mix<Int<20000>,Black,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,255,255>>>>,Bump<Scale<BladeAngle<>,Scale<BladeAngle<0,16000>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-12000>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<10000>>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-10000>>>,Scale<SwingSpeed<100>,Int<14000>,Int<18000>>>>,TrExtend<5000,TrInstant>,TrFade<5000>,EFFECT_LOCKUP_BEGIN>,TrConcat<TrJoin<TrDelay<50>,TrInstant>,Mix<IsLessThan<ClashImpactF<>,Int<26000>>,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,255,255>>,AlphaL<RgbArg<LOCKUP_COLOR_ARG,Rgb<255,255,255>>,Bump<Scale<BladeAngle<>,Scale<BladeAngle<0,16000>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-12000>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<10000>>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-10000>>>,Scale<ClashImpactF<>,Int<20000>,Int<60000>>>>>,TrFade<300>>,TrConcat<TrInstant,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,255,255>>,TrFade<400>>,SaberBase::LOCKUP_NORMAL,Int<1>>,ResponsiveLightningBlockL<Strobe<RgbArg<LB_COLOR_ARG,Rgb<255,255,255>>,AudioFlicker<RgbArg<LB_COLOR_ARG,Rgb<255,255,255>>,Blue>,50,1>,TrConcat<TrExtend<200,TrInstant>,AlphaL<RgbArg<LB_COLOR_ARG,Rgb<255,255,255>>,Bump<Scale<BladeAngle<>,Int<10000>,Int<21000>>,Int<10000>>>,TrFade<200>>,TrConcat<TrInstant,RgbArg<LB_COLOR_ARG,Rgb<255,255,255>>,TrFade<400>>,Int<1>>,LockupTrL<AlphaL<TransitionEffect<RandomPerLEDFlickerL<RgbArg<DRAG_COLOR_ARG,Rgb<255,255,255>>>,BrownNoiseFlickerL<RgbArg<DRAG_COLOR_ARG,Rgb<255,255,255>>,Int<300>>,TrExtend<4000,TrInstant>,TrFade<4000>,EFFECT_DRAG_BEGIN>,SmoothStep<Scale<TwistAngle<>,IntArg<DRAG_SIZE_ARG,28000>,Int<30000>>,Int<3000>>>,TrWipeIn<200>,TrWipe<200>,SaberBase::LOCKUP_DRAG,Int<1>>,LockupTrL<AlphaL<Stripes<2000,4000,Mix<TwistAngle<>,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>,RotateColorsX<Int<3000>,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>>>,Mix<Sin<Int<50>>,Black,Mix<TwistAngle<>,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>,RotateColorsX<Int<3000>,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>>>>,Mix<Int<4096>,Black,Mix<TwistAngle<>,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>,RotateColorsX<Int<3000>,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>>>>>,SmoothStep<Scale<TwistAngle<>,IntArg<MELT_SIZE_ARG,28000>,Int<30000>>,Int<3000>>>,TrConcat<TrExtend<4000,TrWipeIn<200>>,AlphaL<HumpFlicker<Mix<TwistAngle<>,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>,RotateColorsX<Int<3000>,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>>>,RotateColorsX<Int<3000>,Mix<TwistAngle<>,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>,RotateColorsX<Int<3000>,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>>>>,100>,SmoothStep<Scale<TwistAngle<>,IntArg<MELT_SIZE_ARG,28000>,Int<30000>>,Int<3000>>>,TrFade<4000>>,TrWipe<200>,SaberBase::LOCKUP_MELT,Int<1>>,InOutTrL<TrWipeX<BendTimePowInvX<IgnitionTime<300>,Mult<IntArg<IGNITION_OPTION2_ARG,10992>,Int<98304>>>>,TrWipeInX<BendTimePowX<RetractionTime<0>,Mult<IntArg<RETRACTION_OPTION2_ARG,10992>,Int<98304>>>>,Black>>>(),
81

It looks like the code includes the selections but the style information isn’t updating. I’ll have to take a look at scripts to see why. Thanks.

1 Like
82

I found and corrected the bug. You’ll need to refresh the page to get updated scripts, but it will count and display the Base Style Options correctly in the Preview and Style Information.

1 Like
