Good Morning, I apologize for the continued issues and even confusion. I am grateful for your help in solving this puzzle. Current Error at very bottom Though a bit long, I though providing the file in their entirety may help triage the issue.
Ok, so I just re-made the config file this morning from Proffie v3 config for:
Illuminated PCB (Mainblade), Illuminated PCB/Croosguards- parallel, Crystal chamber (3 LED) , Blade detect, OLED, w/ charge port and kill switch:
#ifdef CONFIG_TOP
#include "proffieboard_v3_config.h"
#define NUM_BLADES 7
#define NUM_BUTTONS 2
#define VOLUME 1000
const unsigned int maxLedsPerStrip = 144;
#define CLASH_THRESHOLD_G 1.0
#define ENABLE_AUDIO
#define ENABLE_MOTION
#define ENABLE_WS2811
#define ENABLE_SD
#define SHARED_POWER_PINS
#define BLADE_DETECT_PIN blade5Pin
#define ENABLE_SSD1306
#endif
#ifdef CONFIG_PRESETS
Preset presets[] = {
*has 7 blade entries*
};
Presets no_blade_presets[] = {
*only 1 blade included in file*
};
BladeConfig blades[] = {
{ 0, WS281XBladePtr<144, bladePin, Color8::GRB, PowerPINS<bladePowerPin2, bladePowerPin3> >(),
SubBladeWithStride(0, 15, 2, WS281XBladePtr<16, blade2Pin, Color8::GRB, PowerPINS<bladePowerPin2, bladePowerPin3> >()),
SubBladeWithStride(1, 15, 2, NULL),
WS281XBladePtr<10, blade3Pin, Color8::GRB, PowerPINS<bladePowerPin1> >(),
SubBladeWithStride(0, 15, 2, WS281XBladePtr<16, blade4Pin, Color8::GRB, PowerPINS<bladePowerPin1> >()),
SubBladeWithStride(1, 15, 2, NULL),
WS281XBladePtr<3, blade6Pin, Color8::GRB, PowerPINS<bladePowerPin4> >()
, CONFIGARRAY(presets) },
{ NO_BLADE, $BLADES$ CONFIGARRAY(no_blade_presets), "nb_save" }
,
};
#endif
#ifdef CONFIG_BUTTONS
Button PowerButton(BUTTON_POWER, powerButtonPin, "pow");
Button AuxButton(BUTTON_AUX, auxPin, "aux");
#endif
-------------------------------------------------------------------------------------
Off Fett263: created for "myconfig" / entering in the above blade file (note Fett263 did generate 7 blades):
// ProffieOS7 Config File
#ifdef CONFIG_TOP
#include "proffieboard_v3_config.h"
#define NUM_BLADES 7
#define NUM_BUTTONS 2
const unsigned int maxLedsPerStrip = 144;
#define EXTRA_COLOR_BUFFER_SPACE 60
#define VOLUME 1500
#define BOOT_VOLUME 100
#define CLASH_THRESHOLD_G 3
#define ENABLE_AUDIO
#define ENABLE_MOTION
#define ENABLE_WS2811
#define ENABLE_SD
#define MOTION_TIMEOUT 60 * 5 * 1000
#define IDLE_OFF_TIME 60 * 5 * 1000
#define DISABLE_BASIC_PARSER_STYLES
#define DISABLE_DIAGNOSTIC_COMMANDS
#define ENABLE_ALL_EDIT_OPTIONS
#define SAVE_PRESET
#define NO_REPEAT_RANDOM
#define COLOR_CHANGE_DIRECT
#define BLADE_DETECT_PIN blade5Pin
#define ENABLE_SSD1306
#define FETT263_SAY_BATTERY_PERCENT
#define FETT263_MOTION_WAKE_POWER_BUTTON
#define FETT263_HOLD_BUTTON_LOCKUP
#define FETT263_LOCKUP_DELAY 200
#define FETT263_BM_CLASH_DETECT 6
#define FETT263_THRUST_ON
#define FETT263_THRUST_ON_NO_BM
#define FETT263_TWIST_OFF
#endif
#ifdef CONFIG_PROP
#include "../props/saber_fett263_buttons.h"
#endif
#ifdef CONFIG_PRESETS
Preset presets[] = {
{ "Battle;common", "Battle/tracks/track1.wav",
/* copyright Fett263 Rotoscope (Primary Blade) OS7 Style
https://fett263.com/fett263-proffieOS7-style-library.html#Rotoscope
OS7.12 v1.017-p
This Style Contains 30 Unique Combinations
Style Options:
Default (0): Rotoscope - Single Color (Original Trilogy)
1: Rotoscope - Single Color (Prequels)
2: Audio Rotoscope - Single Color (Original Trilogy)
3: Rotoscope - Single Color (Sequels)
4: Hyper Responsive Rotoscope (Erratic)
Base Color: BaseColorArg (0)
--Effects Included--
Preon Effect Options: Default (0): Faulty Fire Ignition, 1: Erratic (Apocalypse Version), 2: Emitter Heat Up [Color: PreonColorArg]
Ignition Effect Options: Default (0): Standard Ignition, 1: Wipe + Fade [Color: IgnitionColorArg]
PowerUp Effect: Power Burst Emitter [Color: IgnitionColorArg]
Retraction Effect: Standard Retraction [Color: RetractionColorArg]
Lockup Effect: Intensity Lockup V1, Begin Effect: Real Clash, End Effect: Full Blade Absorb [Color: LockupColorArg]
LightningBlock Effect: Responsive Lightning Block [Color: LBColorArg]
Drag Effect: Intensity Sparking Drag [Color: DragColorArg]
Melt Effect: Intensity Melt [Color: StabColorArg]
Blast Effect: Blast Wave (Random) [Color: BlastColorArg]
Clash Effect: Real Clash V1 [Color: ClashColorArg]
Battery Level: % Blade (Green to Red)
*/
StylePtr<Layers<ColorSelect<IntArg<STYLE_OPTION_ARG,0>,TrInstant,RandomFlicker<Stripes<10000,-2600,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RandomFlicker<Stripes<24000,-1400,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<11565>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,AudioFlicker<Stripes<10000,-2600,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RandomFlicker<Stripes<14000,-4000,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,Mix<HoldPeakF<SwingSpeed<250>,Scale<SwingAcceleration<100>,Int<50>,Int<500>>,Scale<SwingAcceleration<>,Int<20000>,Int<10000>>>,Mix<Scale<IsLessThan<SlowNoise<Int<2000>>,Int<18000>>,Int<0>,Int<32768>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Stripes<12000,-800,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,TransitionEffectL<TrConcat<TrJoin<TrDelayX<IgnitionTime<300>>,TrInstant>,AlphaL<Stripes<5000,-2500,RgbArg<IGNITION_COLOR_ARG,Rgb<55,255,169>>,Mix<Int<7710>,Black,RgbArg<IGNITION_COLOR_ARG,Rgb<55,255,169>>>,Mix<Int<3855>,Black,RgbArg<IGNITION_COLOR_ARG,Rgb<55,255,169>>>>,SmoothStep<IntArg<EMITTER_SIZE_ARG,2000>,Int<-500>>>,TrFade<500>>,EFFECT_IGNITION>,TransitionEffectL<TrWaveX<RgbArg<BLAST_COLOR_ARG,Rgb<255,0,75>>,Scale<EffectRandomF<EFFECT_BLAST>,Int<100>,Int<400>>,Int<100>,Scale<EffectPosition<EFFECT_BLAST>,Int<100>,Int<400>>,Scale<EffectPosition<EFFECT_BLAST>,Int<28000>,Int<8000>>>,EFFECT_BLAST>,Mix<IsLessThan<ClashImpactF<>,Int<26000>>,TransitionEffectL<TrConcat<TrInstant,AlphaL<RgbArg<CLASH_COLOR_ARG,Rgb<118,0,194>>,Bump<Scale<BladeAngle<>,Scale<BladeAngle<0,16000>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-12000>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<10000>>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-10000>>>,Scale<ClashImpactF<>,Int<12000>,Int<60000>>>>,TrFadeX<Scale<ClashImpactF<>,Int<200>,Int<400>>>>,EFFECT_CLASH>,TransitionEffectL<TrWaveX<RgbArg<CLASH_COLOR_ARG,Rgb<118,0,194>>,Scale<ClashImpactF<>,Int<100>,Int<400>>,Int<100>,Scale<ClashImpactF<>,Int<100>,Int<400>>,Scale<BladeAngle<>,Scale<BladeAngle<0,16000>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-12000>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<10000>>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-10000>>>>,EFFECT_CLASH>>,LockupTrL<TransitionEffect<AlphaMixL<Bump<Scale<BladeAngle<>,Scale<BladeAngle<0,16000>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-12000>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<10000>>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-10000>>>,Scale<SwingSpeed<100>,Int<14000>,Int<18000>>>,BrownNoiseFlickerL<RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,Int<200>>,StripesX<Int<1800>,Scale<NoisySoundLevel,Int<-3500>,Int<-5000>>,Mix<Int<6425>,Black,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>>,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,Mix<Int<12850>,Black,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>>>>,AlphaL<AudioFlicker<RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,Mix<Int<10280>,Black,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>>>,Bump<Scale<BladeAngle<>,Scale<BladeAngle<0,16000>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-12000>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<10000>>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-10000>>>,Int<13000>>>,TrJoin<TrDelay<8000>,TrInstant>,TrFade<3000>,EFFECT_LOCKUP_BEGIN>,TrConcat<TrJoin<TrDelay<50>,TrInstant>,Mix<IsLessThan<ClashImpactF<>,Int<26000>>,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,AlphaL<RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,Bump<Scale<BladeAngle<>,Scale<BladeAngle<0,16000>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-12000>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<10000>>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-10000>>>,Scale<ClashImpactF<>,Int<20000>,Int<60000>>>>>,TrFade<300>>,TrConcat<TrInstant,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,TrFade<400>>,SaberBase::LOCKUP_NORMAL>,ResponsiveLightningBlockL<Strobe<RgbArg<LB_COLOR_ARG,Rgb<55,255,169>>,AudioFlicker<RgbArg<LB_COLOR_ARG,Rgb<55,255,169>>,Blue>,50,1>,TrConcat<TrInstant,AlphaL<RgbArg<LB_COLOR_ARG,Rgb<55,255,169>>,Bump<Int<12000>,Int<18000>>>,TrFade<200>>,TrConcat<TrInstant,HumpFlickerL<AlphaL<RgbArg<LB_COLOR_ARG,Rgb<55,255,169>>,Int<16000>>,30>,TrSmoothFade<600>>>,LockupTrL<AlphaL<RandomPerLEDFlickerL<RgbArg<DRAG_COLOR_ARG,Rgb<255,0,75>>>,SmoothStep<IntArg<DRAG_SIZE_ARG,28000>,Int<3000>>>,TrConcat<TrJoin<TrDelay<4000>,TrWipeIn<200>>,AlphaL<BrownNoiseFlickerL<RgbArg<DRAG_COLOR_ARG,Rgb<255,0,75>>,Int<300>>,SmoothStep<IntArg<DRAG_SIZE_ARG,28000>,Int<3000>>>,TrFade<4000>>,TrFade<300>,SaberBase::LOCKUP_DRAG>,LockupTrL<AlphaL<Remap<Scale<RampF,Int<65536>,Int<0>>,StaticFire<Mix<TwistAngle<>,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>,RotateColorsX<Int<3000>,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>>>,Mix<TwistAngle<>,RotateColorsX<Int<3000>,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>>,RotateColorsX<Int<3000>,Mix<Int<12000>,Black,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>>>>,0,3,5,3000,10>>,SmoothStep<IntArg<MELT_SIZE_ARG,28000>,Int<4000>>>,TrConcat<TrWipeIn<100>,AlphaL<RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>,SmoothStep<IntArg<MELT_SIZE_ARG,28000>,Int<4000>>>,TrJoin<TrDelay<4000>,TrFade<300>>,AlphaL<Mix<TwistAngle<>,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>,RotateColorsX<Int<3000>,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>>>,SmoothStep<IntArg<MELT_SIZE_ARG,28000>,Int<4000>>>,TrFade<4000>>,TrWipe<200>,SaberBase::LOCKUP_MELT>,InOutTrL<TrSelect<IntArg<IGNITION_OPTION_ARG,0>,TrWipeX<BendTimePowInvX<IgnitionTime<300>,Mult<IntArg<IGNITION_OPTION2_ARG,10992>,Int<98304>>>>,TrJoinR<TrWipeX<BendTimePowInvX<IgnitionTime<300>,Mult<IntArg<IGNITION_OPTION2_ARG,10992>,Int<98304>>>>,TrSmoothFadeX<BendTimePowInvX<IgnitionTime<300>,Mult<IntArg<IGNITION_OPTION2_ARG,10992>,Int<98304>>>>>>,TrWipeInX<BendTimePowInvX<RetractionTime<0>,Mult<IntArg<RETRACTION_OPTION2_ARG,10992>,Int<98304>>>>,Black>,TransitionEffectL<TrSelect<IntArg<PREON_OPTION_ARG,0>,TrConcat<TrExtendX<WavLen<EFFECT_PREON>,TrWipe<100>>,AlphaL<StripesX<Int<3000>,Sin<Int<60>,Int<-1600>,Int<-4000>>,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>,Mix<Int<10772>,Black,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>>,Mix<Int<24000>,Black,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>>>,SmoothStep<NoisySoundLevel,Int<-3000>>>,TrFade<100>>,TrConcat<TrExtendX<Mult<WavLen<EFFECT_PREON>,Int<16384>>,TrInstant>,Layers<AlphaL<Mix<Trigger<EFFECT_PREON,Int<3000>,Int<2000>,Int<1000>>,BrownNoiseFlicker<Black,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>,100>,RandomPerLEDFlicker<RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>,Mix<Int<8192>,Black,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>>>,BrownNoiseFlicker<Mix<NoisySoundLevel,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>,RotateColorsX<Int<4000>,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>>>,RotateColorsX<Int<1200>,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>>,50>>,SmoothStep<Scale<NoisySoundLevel,Int<-1000>,Int<25000>>,Int<-4000>>>,AlphaL<HumpFlickerL<AlphaL<White,Trigger<EFFECT_PREON,Mult<WavLen<EFFECT_PREON>,Int<8176>>,WavLen<EFFECT_PREON>,Mult<WavLen<EFFECT_PREON>,Int<16384>>>>,40>,SmoothStep<IntArg<PREON_SIZE_ARG,5389>,Int<-4000>>>>,TrLoopN<10,TrWaveX<RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>,Int<200>,Int<200>,Scale<Trigger<EFFECT_PREON,Int<0>,Mult<WavLen<EFFECT_PREON>,Int<24576>>,Mult<WavLen<EFFECT_PREON>,Int<8192>>>,Int<400>,Int<100>>,Int<0>>>>,TrConcat<TrExtendX<WavLen<EFFECT_PREON>,TrFade<100>>,AlphaL<HumpFlickerL<Mix<Trigger<EFFECT_PREON,Mult<WavLen<EFFECT_PREON>,Int<24000>>,WavLen<EFFECT_PREON>,Int<500>>,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>,White>,20>,SmoothStep<IntArg<PREON_SIZE_ARG,5389>,Int<-3000>>>,TrFade<200>>>,EFFECT_PREON>,TransitionEffectL<TrConcat<TrJoin<TrDelay<2000>,TrWipe<1000>>,AlphaL<Mix<BatteryLevel,Red,Green>,SmoothStep<BatteryLevel,Int<-10>>>,TrWipeIn<1000>>,EFFECT_BATTERY_LEVEL>>>(),
/* copyright Fett263 Rotoscope (Quillion / Secondary Blade) OS7 Style
https://fett263.com/fett263-proffieOS7-style-library.html#Rotoscope
OS7.12 v1.017-p
This Style Contains 5 Unique Combinations
Style Options:
Default (0): Rotoscope - Single Color (Original Trilogy)
1: Rotoscope - Single Color (Prequels)
2: Audio Rotoscope - Single Color (Original Trilogy)
3: Rotoscope - Single Color (Sequels)
4: Hyper Responsive Rotoscope (Erratic)
Base Color: BaseColorArg (0)
--Effects Included--
Preon Effect: Faulty Ignition (Volatile Version) [Color: PreonColorArg]
Ignition Effect: Standard Ignition [Color: IgnitionColorArg]
Retraction Effect: Standard Retraction [Color: RetractionColorArg]
Lockup Effect: Intensity Lockup Up V1 [Color: LockupColorArg]
LightningBlock Effect: Full Blade Lightning [Color: LBColorArg]
Clash Effect: Clash Ripple Down [Color: ClashColorArg]
*/
StylePtr<Layers<ColorSelect<IntArg<STYLE_OPTION_ARG,0>,TrInstant,RandomFlicker<Stripes<10000,-2600,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RandomFlicker<Stripes<24000,-1400,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<11565>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,AudioFlicker<Stripes<10000,-2600,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RandomFlicker<Stripes<14000,-4000,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,Mix<HoldPeakF<SwingSpeed<250>,Scale<SwingAcceleration<100>,Int<50>,Int<500>>,Scale<SwingAcceleration<>,Int<20000>,Int<10000>>>,Mix<Scale<IsLessThan<SlowNoise<Int<2000>>,Int<18000>>,Int<0>,Int<32768>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Stripes<12000,-800,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,TransitionEffectL<TrConcat<TrInstant,AlphaL<RgbArg<CLASH_COLOR_ARG,Rgb<118,0,194>>,Bump<Int<16384>,Int<6000>>>,TrFade<50>,AlphaL<RgbArg<CLASH_COLOR_ARG,Rgb<118,0,194>>,Int<0>>,TrSparkX<Stripes<2000,2000,RgbArg<CLASH_COLOR_ARG,Rgb<118,0,194>>,Mix<Int<2096>,Black,RgbArg<CLASH_COLOR_ARG,Rgb<118,0,194>>>>,Int<100>,Int<300>,Int<32768>>>,EFFECT_CLASH>,TransitionEffectL<TrConcat<TrInstant,AlphaL<RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,SmoothStep<ClashImpactF<>,Int<-4000>>>,TrFadeX<Scale<ClashImpactF<>,Int<100>,Int<300>>>>,EFFECT_LOCKUP_BEGIN>,TransitionEffectL<TrConcat<TrInstant,AlphaL<RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,Int<0>>,TrSelect<Scale<IsLessThan<ClashImpactF<>,Int<20000>>,Int<1>,Int<0>>,TrWaveX<RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,Scale<ClashImpactF<>,Int<50>,Int<400>>,Int<100>,Scale<ClashImpactF<>,Int<500>,Int<300>>,Int<0>>,TrSparkX<Stripes<1200,-3600,Mix<Int<6425>,Black,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>>,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,Mix<Int<12850>,Black,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>>>,Int<30>,Scale<Sum<ClashImpactF<>,SwingSpeed<600>>,Int<100>,Int<400>>,Int<0>>>>,EFFECT_LOCKUP_END>,LockupTrL<Strobe<RgbArg<LB_COLOR_ARG,Rgb<55,255,169>>,AudioFlicker<RgbArg<LB_COLOR_ARG,Rgb<55,255,169>>,Blue>,50,1>,TrInstant,TrFade<1000>,SaberBase::LOCKUP_LIGHTNING_BLOCK>,InOutTrL<TrWipeX<BendTimePowInvX<IgnitionTime<300>,Mult<IntArg<IGNITION_OPTION2_ARG,10992>,Int<98304>>>>,TrWipeInX<BendTimePowInvX<RetractionTime<0>,Mult<IntArg<RETRACTION_OPTION2_ARG,10992>,Int<98304>>>>,Black>,TransitionEffectL<TrConcat<TrInstant,AlphaL<Mix<Trigger<EFFECT_PREON,Mult<Int<16384>,WavLen<EFFECT_PREON>>,Mult<Int<10922>,WavLen<EFFECT_PREON>>,Mult<Int<5462>,WavLen<EFFECT_PREON>>>,BrownNoiseFlicker<Black,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>,100>,RandomPerLEDFlicker<RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>,Mix<Int<6425>,Black,RotateColorsX<Int<26000>,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>>>>,BrownNoiseFlicker<Mix<NoisySoundLevel,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>,RotateColorsX<Int<26000>,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>>>,RotateColorsX<Int<21845>,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>>,50>>,SmoothStep<Scale<NoisySoundLevel,Int<-10000>,Int<36000>>,Int<-4000>>>,TrDelayX<WavLen<EFFECT_PREON>>>,EFFECT_PREON>>>(),
/* copyright Fett263 Rotoscope (Quillion / Secondary Blade) OS7 Style
https://fett263.com/fett263-proffieOS7-style-library.html#Rotoscope
OS7.12 v1.017-p
This Style Contains 5 Unique Combinations
Style Options:
Default (0): Rotoscope - Single Color (Original Trilogy)
1: Rotoscope - Single Color (Prequels)
2: Audio Rotoscope - Single Color (Original Trilogy)
3: Rotoscope - Single Color (Sequels)
4: Hyper Responsive Rotoscope (Erratic)
Base Color: BaseColorArg (0)
--Effects Included--
Preon Effect: Faulty Ignition (Volatile Version) [Color: PreonColorArg]
Ignition Effect: Standard Ignition [Color: IgnitionColorArg]
Retraction Effect: Standard Retraction [Color: RetractionColorArg]
Lockup Effect: Intensity Lockup Up V1 [Color: LockupColorArg]
LightningBlock Effect: Full Blade Lightning [Color: LBColorArg]
Clash Effect: Clash Ripple Down [Color: ClashColorArg]
*/
StylePtr<Layers<ColorSelect<IntArg<STYLE_OPTION_ARG,0>,TrInstant,RandomFlicker<Stripes<10000,-2600,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RandomFlicker<Stripes<24000,-1400,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<11565>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,AudioFlicker<Stripes<10000,-2600,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RandomFlicker<Stripes<14000,-4000,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,Mix<HoldPeakF<SwingSpeed<250>,Scale<SwingAcceleration<100>,Int<50>,Int<500>>,Scale<SwingAcceleration<>,Int<20000>,Int<10000>>>,Mix<Scale<IsLessThan<SlowNoise<Int<2000>>,Int<18000>>,Int<0>,Int<32768>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Stripes<12000,-800,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,TransitionEffectL<TrConcat<TrInstant,AlphaL<RgbArg<CLASH_COLOR_ARG,Rgb<118,0,194>>,Bump<Int<16384>,Int<6000>>>,TrFade<50>,AlphaL<RgbArg<CLASH_COLOR_ARG,Rgb<118,0,194>>,Int<0>>,TrSparkX<Stripes<2000,2000,RgbArg<CLASH_COLOR_ARG,Rgb<118,0,194>>,Mix<Int<2096>,Black,RgbArg<CLASH_COLOR_ARG,Rgb<118,0,194>>>>,Int<100>,Int<300>,Int<32768>>>,EFFECT_CLASH>,TransitionEffectL<TrConcat<TrInstant,AlphaL<RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,SmoothStep<ClashImpactF<>,Int<-4000>>>,TrFadeX<Scale<ClashImpactF<>,Int<100>,Int<300>>>>,EFFECT_LOCKUP_BEGIN>,TransitionEffectL<TrConcat<TrInstant,AlphaL<RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,Int<0>>,TrSelect<Scale<IsLessThan<ClashImpactF<>,Int<20000>>,Int<1>,Int<0>>,TrWaveX<RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,Scale<ClashImpactF<>,Int<50>,Int<400>>,Int<100>,Scale<ClashImpactF<>,Int<500>,Int<300>>,Int<0>>,TrSparkX<Stripes<1200,-3600,Mix<Int<6425>,Black,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>>,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,Mix<Int<12850>,Black,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>>>,Int<30>,Scale<Sum<ClashImpactF<>,SwingSpeed<600>>,Int<100>,Int<400>>,Int<0>>>>,EFFECT_LOCKUP_END>,LockupTrL<Strobe<RgbArg<LB_COLOR_ARG,Rgb<55,255,169>>,AudioFlicker<RgbArg<LB_COLOR_ARG,Rgb<55,255,169>>,Blue>,50,1>,TrInstant,TrFade<1000>,SaberBase::LOCKUP_LIGHTNING_BLOCK>,InOutTrL<TrWipeX<BendTimePowInvX<IgnitionTime<300>,Mult<IntArg<IGNITION_OPTION2_ARG,10992>,Int<98304>>>>,TrWipeInX<BendTimePowInvX<RetractionTime<0>,Mult<IntArg<RETRACTION_OPTION2_ARG,10992>,Int<98304>>>>,Black>,TransitionEffectL<TrConcat<TrInstant,AlphaL<Mix<Trigger<EFFECT_PREON,Mult<Int<16384>,WavLen<EFFECT_PREON>>,Mult<Int<10922>,WavLen<EFFECT_PREON>>,Mult<Int<5462>,WavLen<EFFECT_PREON>>>,BrownNoiseFlicker<Black,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>,100>,RandomPerLEDFlicker<RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>,Mix<Int<6425>,Black,RotateColorsX<Int<26000>,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>>>>,BrownNoiseFlicker<Mix<NoisySoundLevel,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>,RotateColorsX<Int<26000>,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>>>,RotateColorsX<Int<21845>,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>>,50>>,SmoothStep<Scale<NoisySoundLevel,Int<-10000>,Int<36000>>,Int<-4000>>>,TrDelayX<WavLen<EFFECT_PREON>>>,EFFECT_PREON>>>(),
/* copyright Fett263 Rotoscope (Accent LED / PCB) OS7 Style
https://fett263.com/fett263-proffieOS7-style-library.html#Rotoscope
OS7.12 v1.017-p
This Style Contains 5 Unique Combinations
Style Options:
Default (0): Rotoscope - Single Color (Original Trilogy)
1: Rotoscope - Single Color (Prequels)
2: Audio Rotoscope - Single Color (Original Trilogy)
3: Rotoscope - Single Color (Sequels)
4: Hyper Responsive Rotoscope (Erratic)
Off Behavior: Off [Color: OffColorArg]
Base Color: BaseColorArg (0)
--Effects Included--
Ignition Effect: Instant [Color: IgnitionColorArg]
Retraction Effect: Instant [Color: RetractionColorArg]
*/
StylePtr<Layers<ColorSelect<IntArg<STYLE_OPTION_ARG,0>,TrInstant,RandomFlicker<Stripes<10000,-2600,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RandomFlicker<Stripes<24000,-1400,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<11565>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,AudioFlicker<Stripes<10000,-2600,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RandomFlicker<Stripes<14000,-4000,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,Mix<HoldPeakF<SwingSpeed<250>,Scale<SwingAcceleration<100>,Int<50>,Int<500>>,Scale<SwingAcceleration<>,Int<20000>,Int<10000>>>,Mix<Scale<IsLessThan<SlowNoise<Int<2000>>,Int<18000>>,Int<0>,Int<32768>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Stripes<12000,-800,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,InOutTrL<TrInstant,TrInstant,Black>>>(),
/* copyright Fett263 Rotoscope (Accent LED / PCB) OS7 Style
https://fett263.com/fett263-proffieOS7-style-library.html#Rotoscope
OS7.12 v1.017-p
This Style Contains 5 Unique Combinations
Style Options:
Default (0): Rotoscope - Single Color (Original Trilogy)
1: Rotoscope - Single Color (Prequels)
2: Audio Rotoscope - Single Color (Original Trilogy)
3: Rotoscope - Single Color (Sequels)
4: Hyper Responsive Rotoscope (Erratic)
Off Behavior: Off [Color: OffColorArg]
Base Color: BaseColorArg (0)
--Effects Included--
Ignition Effect: Instant [Color: IgnitionColorArg]
Retraction Effect: Instant [Color: RetractionColorArg]
*/
StylePtr<Layers<ColorSelect<IntArg<STYLE_OPTION_ARG,0>,TrInstant,RandomFlicker<Stripes<10000,-2600,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RandomFlicker<Stripes<24000,-1400,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<11565>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,AudioFlicker<Stripes<10000,-2600,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RandomFlicker<Stripes<14000,-4000,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,Mix<HoldPeakF<SwingSpeed<250>,Scale<SwingAcceleration<100>,Int<50>,Int<500>>,Scale<SwingAcceleration<>,Int<20000>,Int<10000>>>,Mix<Scale<IsLessThan<SlowNoise<Int<2000>>,Int<18000>>,Int<0>,Int<32768>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Stripes<12000,-800,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,InOutTrL<TrInstant,TrInstant,Black>>>(),
/* copyright Fett263 Rotoscope (Accent LED / PCB) OS7 Style
https://fett263.com/fett263-proffieOS7-style-library.html#Rotoscope
OS7.12 v1.017-p
This Style Contains 5 Unique Combinations
Style Options:
Default (0): Rotoscope - Single Color (Original Trilogy)
1: Rotoscope - Single Color (Prequels)
2: Audio Rotoscope - Single Color (Original Trilogy)
3: Rotoscope - Single Color (Sequels)
4: Hyper Responsive Rotoscope (Erratic)
Off Behavior: Off [Color: OffColorArg]
Base Color: BaseColorArg (0)
--Effects Included--
Ignition Effect: Instant [Color: IgnitionColorArg]
Retraction Effect: Instant [Color: RetractionColorArg]
*/
StylePtr<Layers<ColorSelect<IntArg<STYLE_OPTION_ARG,0>,TrInstant,RandomFlicker<Stripes<10000,-2600,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RandomFlicker<Stripes<24000,-1400,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<11565>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,AudioFlicker<Stripes<10000,-2600,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RandomFlicker<Stripes<14000,-4000,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,Mix<HoldPeakF<SwingSpeed<250>,Scale<SwingAcceleration<100>,Int<50>,Int<500>>,Scale<SwingAcceleration<>,Int<20000>,Int<10000>>>,Mix<Scale<IsLessThan<SlowNoise<Int<2000>>,Int<18000>>,Int<0>,Int<32768>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Stripes<12000,-800,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,InOutTrL<TrInstant,TrInstant,Black>>>(),
/* copyright Fett263 Rotoscope (Crystal Chamber) OS7 Style
https://fett263.com/fett263-proffieOS7-style-library.html#Rotoscope
OS7.12 v1.017-p
This Style Contains 5 Unique Combinations
Style Options:
Default (0): Rotoscope - Single Color (Original Trilogy)
1: Rotoscope - Single Color (Prequels)
2: Audio Rotoscope - Single Color (Original Trilogy)
3: Rotoscope - Single Color (Sequels)
4: Hyper Responsive Rotoscope (Erratic)
Off Behavior: Off [Color: OffColorArg]
Base Color: BaseColorArg (0)
--Effects Included--
Ignition Effect: Instant [Color: IgnitionColorArg]
Retraction Effect: Instant [Color: RetractionColorArg]
*/
StylePtr<Layers<ColorSelect<IntArg<STYLE_OPTION_ARG,0>,TrInstant,RandomFlicker<Stripes<10000,-2600,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RandomFlicker<Stripes<24000,-1400,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<11565>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,AudioFlicker<Stripes<10000,-2600,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RandomFlicker<Stripes<14000,-4000,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,Mix<HoldPeakF<SwingSpeed<250>,Scale<SwingAcceleration<100>,Int<50>,Int<500>>,Scale<SwingAcceleration<>,Int<20000>,Int<10000>>>,Mix<Scale<IsLessThan<SlowNoise<Int<2000>>,Int<18000>>,Int<0>,Int<32768>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Stripes<12000,-800,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<16448>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,InOutTrL<TrInstant,TrInstant,Black>>>(),
"Kylo"
},
{ "Battle2;common", "Battle2/tracks/darkside.wav",
/* copyright Fett263 KyloRen (Primary Blade) OS7 Style
https://fett263.com/fett263-proffieOS7-style-library.html#KyloRen
OS7.12 v1.017-p
This Style Contains 12 Unique Combinations
Style Options:
Default (0): Kylo Ren Unstable (Film Based)
1: Kylo Ren Unstable (Supreme Leader)
Base Color: BaseColorArg (0)
--Effects Included--
Preon Effect Options: Default (0): Faulty Fire Ignition, 1: Erratic (Apocalypse Version), 2: Emitter Heat Up [Color: PreonColorArg]
Ignition Effect Options: Default (0): Standard Ignition, 1: Wipe + Fade [Color: IgnitionColorArg]
PowerUp Effect: Power Burst Emitter [Color: IgnitionColorArg]
Retraction Effect: Standard Retraction [Color: RetractionColorArg]
Lockup Effect: Intensity Lockup V1, Begin Effect: Real Clash, End Effect: Full Blade Absorb [Color: LockupColorArg]
LightningBlock Effect: Responsive Lightning Block [Color: LBColorArg]
Drag Effect: Intensity Sparking Drag [Color: DragColorArg]
Melt Effect: Intensity Melt [Color: StabColorArg]
Blast Effect: Blast Wave (Random) [Color: BlastColorArg]
Clash Effect: Real Clash V1 [Color: ClashColorArg]
Battery Level: % Blade (Green to Red)
*/
StylePtr<Layers<ColorSelect<IntArg<STYLE_OPTION_ARG,0>,TrInstant,StaticFire<BrownNoiseFlicker<RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RandomPerLEDFlicker<Mix<Int<3213>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,300>,Mix<Int<10280>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,0,6,10,1000,2>,StripesX<Int<1500>,Scale<SlowNoise<Int<2500>>,Int<-3000>,Int<-5000>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<10280>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<2570>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,TransitionEffectL<TrConcat<TrJoin<TrDelayX<IgnitionTime<300>>,TrInstant>,AlphaL<Stripes<5000,-2500,RgbArg<IGNITION_COLOR_ARG,Rgb<55,255,169>>,Mix<Int<7710>,Black,RgbArg<IGNITION_COLOR_ARG,Rgb<55,255,169>>>,Mix<Int<3855>,Black,RgbArg<IGNITION_COLOR_ARG,Rgb<55,255,169>>>>,SmoothStep<IntArg<EMITTER_SIZE_ARG,2000>,Int<-500>>>,TrFade<500>>,EFFECT_IGNITION>,TransitionEffectL<TrWaveX<RgbArg<BLAST_COLOR_ARG,Rgb<255,0,75>>,Scale<EffectRandomF<EFFECT_BLAST>,Int<100>,Int<400>>,Int<100>,Scale<EffectPosition<EFFECT_BLAST>,Int<100>,Int<400>>,Scale<EffectPosition<EFFECT_BLAST>,Int<28000>,Int<8000>>>,EFFECT_BLAST>,Mix<IsLessThan<ClashImpactF<>,Int<26000>>,TransitionEffectL<TrConcat<TrInstant,AlphaL<RgbArg<CLASH_COLOR_ARG,Rgb<118,0,194>>,Bump<Scale<BladeAngle<>,Scale<BladeAngle<0,16000>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-12000>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<10000>>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-10000>>>,Scale<ClashImpactF<>,Int<12000>,Int<60000>>>>,TrFadeX<Scale<ClashImpactF<>,Int<200>,Int<400>>>>,EFFECT_CLASH>,TransitionEffectL<TrWaveX<RgbArg<CLASH_COLOR_ARG,Rgb<118,0,194>>,Scale<ClashImpactF<>,Int<100>,Int<400>>,Int<100>,Scale<ClashImpactF<>,Int<100>,Int<400>>,Scale<BladeAngle<>,Scale<BladeAngle<0,16000>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-12000>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<10000>>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-10000>>>>,EFFECT_CLASH>>,LockupTrL<TransitionEffect<AlphaMixL<Bump<Scale<BladeAngle<>,Scale<BladeAngle<0,16000>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-12000>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<10000>>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-10000>>>,Scale<SwingSpeed<100>,Int<14000>,Int<18000>>>,BrownNoiseFlickerL<RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,Int<200>>,StripesX<Int<1800>,Scale<NoisySoundLevel,Int<-3500>,Int<-5000>>,Mix<Int<6425>,Black,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>>,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,Mix<Int<12850>,Black,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>>>>,AlphaL<AudioFlicker<RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,Mix<Int<10280>,Black,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>>>,Bump<Scale<BladeAngle<>,Scale<BladeAngle<0,16000>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-12000>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<10000>>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-10000>>>,Int<13000>>>,TrJoin<TrDelay<8000>,TrInstant>,TrFade<3000>,EFFECT_LOCKUP_BEGIN>,TrConcat<TrJoin<TrDelay<50>,TrInstant>,Mix<IsLessThan<ClashImpactF<>,Int<26000>>,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,AlphaL<RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,Bump<Scale<BladeAngle<>,Scale<BladeAngle<0,16000>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-12000>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<10000>>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-10000>>>,Scale<ClashImpactF<>,Int<20000>,Int<60000>>>>>,TrFade<300>>,TrConcat<TrInstant,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,TrFade<400>>,SaberBase::LOCKUP_NORMAL>,ResponsiveLightningBlockL<Strobe<RgbArg<LB_COLOR_ARG,Rgb<55,255,169>>,AudioFlicker<RgbArg<LB_COLOR_ARG,Rgb<55,255,169>>,Blue>,50,1>,TrConcat<TrInstant,AlphaL<RgbArg<LB_COLOR_ARG,Rgb<55,255,169>>,Bump<Int<12000>,Int<18000>>>,TrFade<200>>,TrConcat<TrInstant,HumpFlickerL<AlphaL<RgbArg<LB_COLOR_ARG,Rgb<55,255,169>>,Int<16000>>,30>,TrSmoothFade<600>>>,LockupTrL<AlphaL<RandomPerLEDFlickerL<RgbArg<DRAG_COLOR_ARG,Rgb<255,0,75>>>,SmoothStep<IntArg<DRAG_SIZE_ARG,28000>,Int<3000>>>,TrConcat<TrJoin<TrDelay<4000>,TrWipeIn<200>>,AlphaL<BrownNoiseFlickerL<RgbArg<DRAG_COLOR_ARG,Rgb<255,0,75>>,Int<300>>,SmoothStep<IntArg<DRAG_SIZE_ARG,28000>,Int<3000>>>,TrFade<4000>>,TrFade<300>,SaberBase::LOCKUP_DRAG>,LockupTrL<AlphaL<Remap<Scale<RampF,Int<65536>,Int<0>>,StaticFire<Mix<TwistAngle<>,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>,RotateColorsX<Int<3000>,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>>>,Mix<TwistAngle<>,RotateColorsX<Int<3000>,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>>,RotateColorsX<Int<3000>,Mix<Int<12000>,Black,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>>>>,0,3,5,3000,10>>,SmoothStep<IntArg<MELT_SIZE_ARG,28000>,Int<4000>>>,TrConcat<TrWipeIn<100>,AlphaL<RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>,SmoothStep<IntArg<MELT_SIZE_ARG,28000>,Int<4000>>>,TrJoin<TrDelay<4000>,TrFade<300>>,AlphaL<Mix<TwistAngle<>,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>,RotateColorsX<Int<3000>,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>>>,SmoothStep<IntArg<MELT_SIZE_ARG,28000>,Int<4000>>>,TrFade<4000>>,TrWipe<200>,SaberBase::LOCKUP_MELT>,InOutTrL<TrSelect<IntArg<IGNITION_OPTION_ARG,0>,TrWipeX<BendTimePowInvX<IgnitionTime<300>,Mult<IntArg<IGNITION_OPTION2_ARG,10992>,Int<98304>>>>,TrJoinR<TrWipeX<BendTimePowInvX<IgnitionTime<300>,Mult<IntArg<IGNITION_OPTION2_ARG,10992>,Int<98304>>>>,TrSmoothFadeX<BendTimePowInvX<IgnitionTime<300>,Mult<IntArg<IGNITION_OPTION2_ARG,10992>,Int<98304>>>>>>,TrWipeInX<BendTimePowInvX<RetractionTime<0>,Mult<IntArg<RETRACTION_OPTION2_ARG,10992>,Int<98304>>>>,Black>,TransitionEffectL<TrSelect<IntArg<PREON_OPTION_ARG,0>,TrConcat<TrExtendX<WavLen<EFFECT_PREON>,TrWipe<100>>,AlphaL<StripesX<Int<3000>,Sin<Int<60>,Int<-1600>,Int<-4000>>,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>,Mix<Int<10772>,Black,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>>,Mix<Int<24000>,Black,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>>>,SmoothStep<NoisySoundLevel,Int<-3000>>>,TrFade<100>>,TrConcat<TrExtendX<Mult<WavLen<EFFECT_PREON>,Int<16384>>,TrInstant>,Layers<AlphaL<Mix<Trigger<EFFECT_PREON,Int<3000>,Int<2000>,Int<1000>>,BrownNoiseFlicker<Black,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>,100>,RandomPerLEDFlicker<RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>,Mix<Int<8192>,Black,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>>>,BrownNoiseFlicker<Mix<NoisySoundLevel,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>,RotateColorsX<Int<4000>,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>>>,RotateColorsX<Int<1200>,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>>,50>>,SmoothStep<Scale<NoisySoundLevel,Int<-1000>,Int<25000>>,Int<-4000>>>,AlphaL<HumpFlickerL<AlphaL<White,Trigger<EFFECT_PREON,Mult<WavLen<EFFECT_PREON>,Int<8176>>,WavLen<EFFECT_PREON>,Mult<WavLen<EFFECT_PREON>,Int<16384>>>>,40>,SmoothStep<IntArg<PREON_SIZE_ARG,5389>,Int<-4000>>>>,TrLoopN<10,TrWaveX<RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>,Int<200>,Int<200>,Scale<Trigger<EFFECT_PREON,Int<0>,Mult<WavLen<EFFECT_PREON>,Int<24576>>,Mult<WavLen<EFFECT_PREON>,Int<8192>>>,Int<400>,Int<100>>,Int<0>>>>,TrConcat<TrExtendX<WavLen<EFFECT_PREON>,TrFade<100>>,AlphaL<HumpFlickerL<Mix<Trigger<EFFECT_PREON,Mult<WavLen<EFFECT_PREON>,Int<24000>>,WavLen<EFFECT_PREON>,Int<500>>,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>,White>,20>,SmoothStep<IntArg<PREON_SIZE_ARG,5389>,Int<-3000>>>,TrFade<200>>>,EFFECT_PREON>,TransitionEffectL<TrConcat<TrJoin<TrDelay<2000>,TrWipe<1000>>,AlphaL<Mix<BatteryLevel,Red,Green>,SmoothStep<BatteryLevel,Int<-10>>>,TrWipeIn<1000>>,EFFECT_BATTERY_LEVEL>>>(),
/* copyright Fett263 KyloRen (Quillion / Secondary Blade) OS7 Style
https://fett263.com/fett263-proffieOS7-style-library.html#KyloRen
OS7.12 v1.017-p
This Style Contains 2 Unique Combinations
Style Options:
Default (0): Kylo Ren Unstable (Film Based)
1: Kylo Ren Unstable (Supreme Leader)
Base Color: BaseColorArg (0)
--Effects Included--
Preon Effect: Faulty Ignition (Volatile Version) [Color: PreonColorArg]
Ignition Effect: Standard Ignition [Color: IgnitionColorArg]
Retraction Effect: Standard Retraction [Color: RetractionColorArg]
Lockup Effect: Intensity Lockup Up V1 [Color: LockupColorArg]
LightningBlock Effect: Full Blade Lightning [Color: LBColorArg]
Clash Effect: Clash Ripple Down [Color: ClashColorArg]
*/
StylePtr<Layers<ColorSelect<IntArg<STYLE_OPTION_ARG,0>,TrInstant,StaticFire<BrownNoiseFlicker<RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RandomPerLEDFlicker<Mix<Int<3213>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,300>,Mix<Int<10280>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,0,6,10,1000,2>,StripesX<Int<1500>,Scale<SlowNoise<Int<2500>>,Int<-3000>,Int<-5000>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<10280>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<2570>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,TransitionEffectL<TrConcat<TrInstant,AlphaL<RgbArg<CLASH_COLOR_ARG,Rgb<118,0,194>>,Bump<Int<16384>,Int<6000>>>,TrFade<50>,AlphaL<RgbArg<CLASH_COLOR_ARG,Rgb<118,0,194>>,Int<0>>,TrSparkX<Stripes<2000,2000,RgbArg<CLASH_COLOR_ARG,Rgb<118,0,194>>,Mix<Int<2096>,Black,RgbArg<CLASH_COLOR_ARG,Rgb<118,0,194>>>>,Int<100>,Int<300>,Int<32768>>>,EFFECT_CLASH>,TransitionEffectL<TrConcat<TrInstant,AlphaL<RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,SmoothStep<ClashImpactF<>,Int<-4000>>>,TrFadeX<Scale<ClashImpactF<>,Int<100>,Int<300>>>>,EFFECT_LOCKUP_BEGIN>,TransitionEffectL<TrConcat<TrInstant,AlphaL<RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,Int<0>>,TrSelect<Scale<IsLessThan<ClashImpactF<>,Int<20000>>,Int<1>,Int<0>>,TrWaveX<RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,Scale<ClashImpactF<>,Int<50>,Int<400>>,Int<100>,Scale<ClashImpactF<>,Int<500>,Int<300>>,Int<0>>,TrSparkX<Stripes<1200,-3600,Mix<Int<6425>,Black,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>>,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,Mix<Int<12850>,Black,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>>>,Int<30>,Scale<Sum<ClashImpactF<>,SwingSpeed<600>>,Int<100>,Int<400>>,Int<0>>>>,EFFECT_LOCKUP_END>,LockupTrL<Strobe<RgbArg<LB_COLOR_ARG,Rgb<55,255,169>>,AudioFlicker<RgbArg<LB_COLOR_ARG,Rgb<55,255,169>>,Blue>,50,1>,TrInstant,TrFade<1000>,SaberBase::LOCKUP_LIGHTNING_BLOCK>,InOutTrL<TrWipeX<BendTimePowInvX<IgnitionTime<300>,Mult<IntArg<IGNITION_OPTION2_ARG,10992>,Int<98304>>>>,TrWipeInX<BendTimePowInvX<RetractionTime<0>,Mult<IntArg<RETRACTION_OPTION2_ARG,10992>,Int<98304>>>>,Black>,TransitionEffectL<TrConcat<TrInstant,AlphaL<Mix<Trigger<EFFECT_PREON,Mult<Int<16384>,WavLen<EFFECT_PREON>>,Mult<Int<10922>,WavLen<EFFECT_PREON>>,Mult<Int<5462>,WavLen<EFFECT_PREON>>>,BrownNoiseFlicker<Black,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>,100>,RandomPerLEDFlicker<RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>,Mix<Int<6425>,Black,RotateColorsX<Int<26000>,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>>>>,BrownNoiseFlicker<Mix<NoisySoundLevel,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>,RotateColorsX<Int<26000>,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>>>,RotateColorsX<Int<21845>,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>>,50>>,SmoothStep<Scale<NoisySoundLevel,Int<-10000>,Int<36000>>,Int<-4000>>>,TrDelayX<WavLen<EFFECT_PREON>>>,EFFECT_PREON>>>(),
/* copyright Fett263 KyloRen (Quillion / Secondary Blade) OS7 Style
https://fett263.com/fett263-proffieOS7-style-library.html#KyloRen
OS7.12 v1.017-p
This Style Contains 2 Unique Combinations
Style Options:
Default (0): Kylo Ren Unstable (Film Based)
1: Kylo Ren Unstable (Supreme Leader)
Base Color: BaseColorArg (0)
--Effects Included--
Preon Effect: Faulty Ignition (Volatile Version) [Color: PreonColorArg]
Ignition Effect: Standard Ignition [Color: IgnitionColorArg]
Retraction Effect: Standard Retraction [Color: RetractionColorArg]
Lockup Effect: Intensity Lockup Up V1 [Color: LockupColorArg]
LightningBlock Effect: Full Blade Lightning [Color: LBColorArg]
Clash Effect: Clash Ripple Down [Color: ClashColorArg]
*/
StylePtr<Layers<ColorSelect<IntArg<STYLE_OPTION_ARG,0>,TrInstant,StaticFire<BrownNoiseFlicker<RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RandomPerLEDFlicker<Mix<Int<3213>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,300>,Mix<Int<10280>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,0,6,10,1000,2>,StripesX<Int<1500>,Scale<SlowNoise<Int<2500>>,Int<-3000>,Int<-5000>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<10280>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<2570>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,TransitionEffectL<TrConcat<TrInstant,AlphaL<RgbArg<CLASH_COLOR_ARG,Rgb<118,0,194>>,Bump<Int<16384>,Int<6000>>>,TrFade<50>,AlphaL<RgbArg<CLASH_COLOR_ARG,Rgb<118,0,194>>,Int<0>>,TrSparkX<Stripes<2000,2000,RgbArg<CLASH_COLOR_ARG,Rgb<118,0,194>>,Mix<Int<2096>,Black,RgbArg<CLASH_COLOR_ARG,Rgb<118,0,194>>>>,Int<100>,Int<300>,Int<32768>>>,EFFECT_CLASH>,TransitionEffectL<TrConcat<TrInstant,AlphaL<RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,SmoothStep<ClashImpactF<>,Int<-4000>>>,TrFadeX<Scale<ClashImpactF<>,Int<100>,Int<300>>>>,EFFECT_LOCKUP_BEGIN>,TransitionEffectL<TrConcat<TrInstant,AlphaL<RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,Int<0>>,TrSelect<Scale<IsLessThan<ClashImpactF<>,Int<20000>>,Int<1>,Int<0>>,TrWaveX<RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,Scale<ClashImpactF<>,Int<50>,Int<400>>,Int<100>,Scale<ClashImpactF<>,Int<500>,Int<300>>,Int<0>>,TrSparkX<Stripes<1200,-3600,Mix<Int<6425>,Black,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>>,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>,Mix<Int<12850>,Black,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,0,0>>>>,Int<30>,Scale<Sum<ClashImpactF<>,SwingSpeed<600>>,Int<100>,Int<400>>,Int<0>>>>,EFFECT_LOCKUP_END>,LockupTrL<Strobe<RgbArg<LB_COLOR_ARG,Rgb<55,255,169>>,AudioFlicker<RgbArg<LB_COLOR_ARG,Rgb<55,255,169>>,Blue>,50,1>,TrInstant,TrFade<1000>,SaberBase::LOCKUP_LIGHTNING_BLOCK>,InOutTrL<TrWipeX<BendTimePowInvX<IgnitionTime<300>,Mult<IntArg<IGNITION_OPTION2_ARG,10992>,Int<98304>>>>,TrWipeInX<BendTimePowInvX<RetractionTime<0>,Mult<IntArg<RETRACTION_OPTION2_ARG,10992>,Int<98304>>>>,Black>,TransitionEffectL<TrConcat<TrInstant,AlphaL<Mix<Trigger<EFFECT_PREON,Mult<Int<16384>,WavLen<EFFECT_PREON>>,Mult<Int<10922>,WavLen<EFFECT_PREON>>,Mult<Int<5462>,WavLen<EFFECT_PREON>>>,BrownNoiseFlicker<Black,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>,100>,RandomPerLEDFlicker<RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>,Mix<Int<6425>,Black,RotateColorsX<Int<26000>,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>>>>,BrownNoiseFlicker<Mix<NoisySoundLevel,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>,RotateColorsX<Int<26000>,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>>>,RotateColorsX<Int<21845>,RgbArg<PREON_COLOR_ARG,Rgb<255,0,255>>>,50>>,SmoothStep<Scale<NoisySoundLevel,Int<-10000>,Int<36000>>,Int<-4000>>>,TrDelayX<WavLen<EFFECT_PREON>>>,EFFECT_PREON>>>(),
/* copyright Fett263 KyloRen (Accent LED / PCB) OS7 Style
https://fett263.com/fett263-proffieOS7-style-library.html#KyloRen
OS7.12 v1.017-p
This Style Contains 2 Unique Combinations
Style Options:
Default (0): Kylo Ren Unstable (Film Based)
1: Kylo Ren Unstable (Supreme Leader)
Off Behavior: Off [Color: OffColorArg]
Base Color: BaseColorArg (0)
--Effects Included--
Ignition Effect: Instant [Color: IgnitionColorArg]
Retraction Effect: Instant [Color: RetractionColorArg]
*/
StylePtr<Layers<ColorSelect<IntArg<STYLE_OPTION_ARG,0>,TrInstant,StaticFire<BrownNoiseFlicker<RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RandomPerLEDFlicker<Mix<Int<3213>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,300>,Mix<Int<10280>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,0,6,10,1000,2>,StripesX<Int<1500>,Scale<SlowNoise<Int<2500>>,Int<-3000>,Int<-5000>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<10280>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<2570>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,InOutTrL<TrInstant,TrInstant,Black>>>(),
/* copyright Fett263 KyloRen (Accent LED / PCB) OS7 Style
https://fett263.com/fett263-proffieOS7-style-library.html#KyloRen
OS7.12 v1.017-p
This Style Contains 2 Unique Combinations
Style Options:
Default (0): Kylo Ren Unstable (Film Based)
1: Kylo Ren Unstable (Supreme Leader)
Off Behavior: Off [Color: OffColorArg]
Base Color: BaseColorArg (0)
--Effects Included--
Ignition Effect: Instant [Color: IgnitionColorArg]
Retraction Effect: Instant [Color: RetractionColorArg]
*/
StylePtr<Layers<ColorSelect<IntArg<STYLE_OPTION_ARG,0>,TrInstant,StaticFire<BrownNoiseFlicker<RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RandomPerLEDFlicker<Mix<Int<3213>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,300>,Mix<Int<10280>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,0,6,10,1000,2>,StripesX<Int<1500>,Scale<SlowNoise<Int<2500>>,Int<-3000>,Int<-5000>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<10280>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<2570>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,InOutTrL<TrInstant,TrInstant,Black>>>(),
/* copyright Fett263 KyloRen (Accent LED / PCB) OS7 Style
https://fett263.com/fett263-proffieOS7-style-library.html#KyloRen
OS7.12 v1.017-p
This Style Contains 2 Unique Combinations
Style Options:
Default (0): Kylo Ren Unstable (Film Based)
1: Kylo Ren Unstable (Supreme Leader)
Off Behavior: Off [Color: OffColorArg]
Base Color: BaseColorArg (0)
--Effects Included--
Ignition Effect: Instant [Color: IgnitionColorArg]
Retraction Effect: Instant [Color: RetractionColorArg]
*/
StylePtr<Layers<ColorSelect<IntArg<STYLE_OPTION_ARG,0>,TrInstant,StaticFire<BrownNoiseFlicker<RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RandomPerLEDFlicker<Mix<Int<3213>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,300>,Mix<Int<10280>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,0,6,10,1000,2>,StripesX<Int<1500>,Scale<SlowNoise<Int<2500>>,Int<-3000>,Int<-5000>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<10280>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<2570>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,InOutTrL<TrInstant,TrInstant,Black>>>(),
/* copyright Fett263 KyloRen (Crystal Chamber) OS7 Style
https://fett263.com/fett263-proffieOS7-style-library.html#KyloRen
OS7.12 v1.017-p
This Style Contains 2 Unique Combinations
Style Options:
Default (0): Kylo Ren Unstable (Film Based)
1: Kylo Ren Unstable (Supreme Leader)
Off Behavior: Off [Color: OffColorArg]
Base Color: BaseColorArg (0)
--Effects Included--
Ignition Effect: Instant [Color: IgnitionColorArg]
Retraction Effect: Instant [Color: RetractionColorArg]
*/
StylePtr<Layers<ColorSelect<IntArg<STYLE_OPTION_ARG,0>,TrInstant,StaticFire<BrownNoiseFlicker<RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,RandomPerLEDFlicker<Mix<Int<3213>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,Mix<Int<7710>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,300>,Mix<Int<10280>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,0,6,10,1000,2>,StripesX<Int<1500>,Scale<SlowNoise<Int<2500>>,Int<-3000>,Int<-5000>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<10280>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>,Mix<Int<2570>,Black,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>,RgbArg<BASE_COLOR_ARG,Rgb<108,255,6>>>>,InOutTrL<TrInstant,TrInstant,Black>>>(),
"preset1"
},
};
Preset no_blade presets[] = {
{ "Battle3;common", "Battle3/tracks/luke.wav",
/* copyright Fett263 JediSurvivor (Primary Blade) OS7 Style
https://fett263.com/fett263-proffieOS7-style-library.html#JediSurvivor
OS7.13 v1.018-p
Single Style
Base Style: Cal Kestis Survivor Blue
Base Color: BaseColorArg (0)
--Effects Included--
Ignition Effect: Standard Ignition [Color: IgnitionColorArg]
Retraction Effect: Standard Retraction [Color: RetractionColorArg]
Lockup Effect: Intensity Lockup V1, Begin Effect: Real Clash, End Effect: Full Blade Absorb [Color: LockupColorArg]
LightningBlock Effect: Responsive Lightning Block [Color: LBColorArg]
Drag Effect: Intensity Sparking Drag [Color: DragColorArg]
Melt Effect: Intensity Melt [Color: StabColorArg]
Blast Effect: Blast Wave (Random) [Color: BlastColorArg]
Clash Effect: Real Clash V1 [Color: ClashColorArg]
*/
StylePtr<Layers<StripesX<Scale<HoldPeakF<Sum<EffectPulseF<EFFECT_IGNITION>,EffectPulseF<EFFECT_ALT_SOUND>>,Int<3000>,Int<3000>>,Int<8000>,Int<3000>>,Scale<HoldPeakF<Sum<EffectPulseF<EFFECT_IGNITION>,EffectPulseF<EFFECT_ALT_SOUND>>,Int<3000>,Int<3000>>,Int<-2600>,Int<-3600>>,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>,Mix<Int<12000>,Black,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>>,Pulsing<RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>,Mix<Int<8000>,Black,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>>,1400>>,TransitionEffectL<TrWaveX<RgbArg<BLAST_COLOR_ARG,Rgb<255,255,255>>,Scale<EffectRandomF<EFFECT_BLAST>,Int<100>,Int<400>>,Int<100>,Scale<EffectPosition<EFFECT_BLAST>,Int<100>,Int<400>>,Scale<EffectPosition<EFFECT_BLAST>,Int<28000>,Int<8000>>>,EFFECT_BLAST>,Mix<IsLessThan<ClashImpactF<>,Int<26000>>,TransitionEffectL<TrConcat<TrInstant,AlphaL<RgbArg<CLASH_COLOR_ARG,Rgb<255,255,255>>,Bump<Scale<BladeAngle<>,Scale<BladeAngle<0,16000>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-12000>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<10000>>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-10000>>>,Scale<ClashImpactF<>,Int<12000>,Int<60000>>>>,TrFadeX<Scale<ClashImpactF<>,Int<200>,Int<400>>>>,EFFECT_CLASH>,TransitionEffectL<TrWaveX<RgbArg<CLASH_COLOR_ARG,Rgb<255,255,255>>,Scale<ClashImpactF<>,Int<100>,Int<400>>,Int<100>,Scale<ClashImpactF<>,Int<100>,Int<400>>,Scale<BladeAngle<>,Scale<BladeAngle<0,16000>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-12000>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<10000>>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-10000>>>>,EFFECT_CLASH>>,LockupTrL<TransitionEffect<AlphaMixL<Bump<Scale<BladeAngle<>,Scale<BladeAngle<0,16000>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-12000>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<10000>>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-10000>>>,Scale<SwingSpeed<100>,Int<14000>,Int<18000>>>,BrownNoiseFlickerL<RgbArg<LOCKUP_COLOR_ARG,Rgb<255,255,255>>,Int<200>>,StripesX<Int<1800>,Scale<NoisySoundLevel,Int<-3500>,Int<-5000>>,Mix<Int<6425>,Black,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,255,255>>>,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,255,255>>,Mix<Int<12850>,Black,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,255,255>>>>>,AlphaL<AudioFlicker<RgbArg<LOCKUP_COLOR_ARG,Rgb<255,255,255>>,Mix<Int<10280>,Black,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,255,255>>>>,Bump<Scale<BladeAngle<>,Scale<BladeAngle<0,16000>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-12000>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<10000>>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-10000>>>,Int<13000>>>,TrJoin<TrDelay<8000>,TrInstant>,TrFade<3000>,EFFECT_LOCKUP_BEGIN>,TrConcat<TrJoin<TrDelay<50>,TrInstant>,Mix<IsLessThan<ClashImpactF<>,Int<26000>>,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,255,255>>,AlphaL<RgbArg<LOCKUP_COLOR_ARG,Rgb<255,255,255>>,Bump<Scale<BladeAngle<>,Scale<BladeAngle<0,16000>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-12000>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<10000>>>,Sum<IntArg<LOCKUP_POSITION_ARG,16000>,Int<-10000>>>,Scale<ClashImpactF<>,Int<20000>,Int<60000>>>>>,TrFade<300>>,TrConcat<TrInstant,RgbArg<LOCKUP_COLOR_ARG,Rgb<255,255,255>>,TrFade<400>>,SaberBase::LOCKUP_NORMAL>,ResponsiveLightningBlockL<Strobe<RgbArg<LB_COLOR_ARG,Rgb<255,255,255>>,AudioFlicker<RgbArg<LB_COLOR_ARG,Rgb<255,255,255>>,Blue>,50,1>,TrConcat<TrInstant,AlphaL<RgbArg<LB_COLOR_ARG,Rgb<255,255,255>>,Bump<Int<12000>,Int<18000>>>,TrFade<200>>,TrConcat<TrInstant,HumpFlickerL<AlphaL<RgbArg<LB_COLOR_ARG,Rgb<255,255,255>>,Int<16000>>,30>,TrSmoothFade<600>>>,LockupTrL<AlphaL<RandomPerLEDFlickerL<RgbArg<DRAG_COLOR_ARG,Rgb<255,255,255>>>,SmoothStep<IntArg<DRAG_SIZE_ARG,28000>,Int<3000>>>,TrConcat<TrJoin<TrDelay<4000>,TrWipeIn<200>>,AlphaL<BrownNoiseFlickerL<RgbArg<DRAG_COLOR_ARG,Rgb<255,255,255>>,Int<300>>,SmoothStep<IntArg<DRAG_SIZE_ARG,28000>,Int<3000>>>,TrFade<4000>>,TrFade<300>,SaberBase::LOCKUP_DRAG>,LockupTrL<AlphaL<Remap<Scale<RampF,Int<65536>,Int<0>>,StaticFire<Mix<TwistAngle<>,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>,RotateColorsX<Int<3000>,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>>>,Mix<TwistAngle<>,RotateColorsX<Int<3000>,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>>,RotateColorsX<Int<3000>,Mix<Int<12000>,Black,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>>>>,0,3,5,3000,10>>,SmoothStep<IntArg<MELT_SIZE_ARG,28000>,Int<4000>>>,TrConcat<TrWipeIn<100>,AlphaL<RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>,SmoothStep<IntArg<MELT_SIZE_ARG,28000>,Int<4000>>>,TrJoin<TrDelay<4000>,TrFade<300>>,AlphaL<Mix<TwistAngle<>,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>,RotateColorsX<Int<3000>,RgbArg<STAB_COLOR_ARG,Rgb<255,68,0>>>>,SmoothStep<IntArg<MELT_SIZE_ARG,28000>,Int<4000>>>,TrFade<4000>>,TrWipe<200>,SaberBase::LOCKUP_MELT>,InOutTrL<TrWipeX<BendTimePowInvX<IgnitionTime<300>,Mult<IntArg<IGNITION_OPTION2_ARG,10992>,Int<98304>>>>,TrWipeInX<BendTimePowInvX<RetractionTime<0>,Mult<IntArg<RETRACTION_OPTION2_ARG,10992>,Int<98304>>>>,Black>>>(),
/* copyright Fett263 JediSurvivor (Accent LED / PCB) OS7 Style
https://fett263.com/fett263-proffieOS7-style-library.html#JediSurvivor
OS7.13 v1.018-p
Single Style
Base Style: Cal Kestis Survivor Blue
Off Behavior: Off [Color: OffColorArg]
Base Color: BaseColorArg (0)
--Effects Included--
Ignition Effect: Instant [Color: IgnitionColorArg]
Retraction Effect: Instant [Color: RetractionColorArg]
*/
StylePtr<Layers<StripesX<Scale<HoldPeakF<Sum<EffectPulseF<EFFECT_IGNITION>,EffectPulseF<EFFECT_ALT_SOUND>>,Int<3000>,Int<3000>>,Int<8000>,Int<3000>>,Scale<HoldPeakF<Sum<EffectPulseF<EFFECT_IGNITION>,EffectPulseF<EFFECT_ALT_SOUND>>,Int<3000>,Int<3000>>,Int<-2600>,Int<-3600>>,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>,Mix<Int<12000>,Black,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>>,Pulsing<RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>,Mix<Int<8000>,Black,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>>,1400>>,InOutTrL<TrInstant,TrInstant,Black>>>(),
/* copyright Fett263 JediSurvivor (Quillion / Secondary Blade) OS7 Style
https://fett263.com/fett263-proffieOS7-style-library.html#JediSurvivor
OS7.13 v1.018-p
Single Style
Base Style: Cal Kestis Survivor Blue
Base Color: BaseColorArg (0)
--Effects Included--
Ignition Effect: Standard Ignition [Color: IgnitionColorArg]
Retraction Effect: Standard Retraction [Color: RetractionColorArg]
*/
StylePtr<Layers<StripesX<Scale<HoldPeakF<Sum<EffectPulseF<EFFECT_IGNITION>,EffectPulseF<EFFECT_ALT_SOUND>>,Int<3000>,Int<3000>>,Int<8000>,Int<3000>>,Scale<HoldPeakF<Sum<EffectPulseF<EFFECT_IGNITION>,EffectPulseF<EFFECT_ALT_SOUND>>,Int<3000>,Int<3000>>,Int<-2600>,Int<-3600>>,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>,Mix<Int<12000>,Black,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>>,Pulsing<RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>,Mix<Int<8000>,Black,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>>,1400>>,InOutTrL<TrWipeX<BendTimePowInvX<IgnitionTime<300>,Mult<IntArg<IGNITION_OPTION2_ARG,10992>,Int<98304>>>>,TrWipeInX<BendTimePowInvX<RetractionTime<0>,Mult<IntArg<RETRACTION_OPTION2_ARG,10992>,Int<98304>>>>,Black>>>(),
/* copyright Fett263 JediSurvivor (Quillion / Secondary Blade) OS7 Style
https://fett263.com/fett263-proffieOS7-style-library.html#JediSurvivor
OS7.13 v1.018-p
Single Style
Base Style: Cal Kestis Survivor Blue
Base Color: BaseColorArg (0)
--Effects Included--
Ignition Effect: Standard Ignition [Color: IgnitionColorArg]
Retraction Effect: Standard Retraction [Color: RetractionColorArg]
*/
StylePtr<Layers<StripesX<Scale<HoldPeakF<Sum<EffectPulseF<EFFECT_IGNITION>,EffectPulseF<EFFECT_ALT_SOUND>>,Int<3000>,Int<3000>>,Int<8000>,Int<3000>>,Scale<HoldPeakF<Sum<EffectPulseF<EFFECT_IGNITION>,EffectPulseF<EFFECT_ALT_SOUND>>,Int<3000>,Int<3000>>,Int<-2600>,Int<-3600>>,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>,Mix<Int<12000>,Black,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>>,Pulsing<RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>,Mix<Int<8000>,Black,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>>,1400>>,InOutTrL<TrWipeX<BendTimePowInvX<IgnitionTime<300>,Mult<IntArg<IGNITION_OPTION2_ARG,10992>,Int<98304>>>>,TrWipeInX<BendTimePowInvX<RetractionTime<0>,Mult<IntArg<RETRACTION_OPTION2_ARG,10992>,Int<98304>>>>,Black>>>(),
/* copyright Fett263 JediSurvivor (Accent LED / PCB) OS7 Style
https://fett263.com/fett263-proffieOS7-style-library.html#JediSurvivor
OS7.13 v1.018-p
Single Style
Base Style: Cal Kestis Survivor Blue
Off Behavior: Off [Color: OffColorArg]
Base Color: BaseColorArg (0)
--Effects Included--
Ignition Effect: Instant [Color: IgnitionColorArg]
Retraction Effect: Instant [Color: RetractionColorArg]
*/
StylePtr<Layers<StripesX<Scale<HoldPeakF<Sum<EffectPulseF<EFFECT_IGNITION>,EffectPulseF<EFFECT_ALT_SOUND>>,Int<3000>,Int<3000>>,Int<8000>,Int<3000>>,Scale<HoldPeakF<Sum<EffectPulseF<EFFECT_IGNITION>,EffectPulseF<EFFECT_ALT_SOUND>>,Int<3000>,Int<3000>>,Int<-2600>,Int<-3600>>,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>,Mix<Int<12000>,Black,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>>,Pulsing<RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>,Mix<Int<8000>,Black,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>>,1400>>,InOutTrL<TrInstant,TrInstant,Black>>>(),
/* copyright Fett263 JediSurvivor (Accent LED / PCB) OS7 Style
https://fett263.com/fett263-proffieOS7-style-library.html#JediSurvivor
OS7.13 v1.018-p
Single Style
Base Style: Cal Kestis Survivor Blue
Off Behavior: Off [Color: OffColorArg]
Base Color: BaseColorArg (0)
--Effects Included--
Ignition Effect: Instant [Color: IgnitionColorArg]
Retraction Effect: Instant [Color: RetractionColorArg]
*/
StylePtr<Layers<StripesX<Scale<HoldPeakF<Sum<EffectPulseF<EFFECT_IGNITION>,EffectPulseF<EFFECT_ALT_SOUND>>,Int<3000>,Int<3000>>,Int<8000>,Int<3000>>,Scale<HoldPeakF<Sum<EffectPulseF<EFFECT_IGNITION>,EffectPulseF<EFFECT_ALT_SOUND>>,Int<3000>,Int<3000>>,Int<-2600>,Int<-3600>>,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>,Mix<Int<12000>,Black,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>>,Pulsing<RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>,Mix<Int<8000>,Black,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>>,1400>>,InOutTrL<TrInstant,TrInstant,Black>>>(),
/* copyright Fett263 JediSurvivor (Crystal Chamber) OS7 Style
https://fett263.com/fett263-proffieOS7-style-library.html#JediSurvivor
OS7.13 v1.018-p
Single Style
Base Style: Cal Kestis Survivor Blue
Off Behavior: Off [Color: OffColorArg]
Base Color: BaseColorArg (0)
--Effects Included--
Ignition Effect: Instant [Color: IgnitionColorArg]
Retraction Effect: Instant [Color: RetractionColorArg]
*/
StylePtr<Layers<StripesX<Scale<HoldPeakF<Sum<EffectPulseF<EFFECT_IGNITION>,EffectPulseF<EFFECT_ALT_SOUND>>,Int<3000>,Int<3000>>,Int<8000>,Int<3000>>,Scale<HoldPeakF<Sum<EffectPulseF<EFFECT_IGNITION>,EffectPulseF<EFFECT_ALT_SOUND>>,Int<3000>,Int<3000>>,Int<-2600>,Int<-3600>>,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>,Mix<Int<12000>,Black,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>>,Pulsing<RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>,Mix<Int<8000>,Black,RgbArg<BASE_COLOR_ARG,Rgb<0,0,255>>>,1400>>,InOutTrL<TrInstant,TrInstant,Black>>>(),
"preset0"
},
};
BladeConfig blades[] = {
{ 0, WS281XBladePtr<144, bladePin, Color8::GRB, PowerPINS<bladePowerPin2, bladePowerPin3> >(),
SubBladeWithStride(0, 15, 2, WS281XBladePtr<16, blade2Pin, Color8::GRB, PowerPINS<bladePowerPin2, bladePowerPin3> >()),
SubBladeWithStride(1, 15, 2, NULL),
WS281XBladePtr<144, blade3Pin, Color8::GRB, PowerPINS<bladePowerPin1> >(),
SubBladeWithStride(0, 15, 2, WS281XBladePtr<16, blade4Pin, Color8::GRB, PowerPINS<bladePowerPin1> >()),
SubBladeWithStride(1, 15, 2, NULL),
WS281XBladePtr<3, blade6Pin, Color8::GRB, PowerPINS<bladePowerPin4> >()
, CONFIGARRAY(presets) },
{ NO_BLADE, WS281XBladePtr<10, bladePin, Color8::GRB, PowerPINS<bladePowerPin2, bladePowerPin3> >(),
SubBladeWithStride(0, 15, 2, WS281XBladePtr<16, blade2Pin, Color8::GRB, PowerPINS<bladePowerPin2, bladePowerPin3> >()),
SubBladeWithStride(1, 15, 2, NULL),
WS281XBladePtr<144, blade3Pin, Color8::GRB, PowerPINS<bladePowerPin1> >(),
SubBladeWithStride(0, 15, 2, WS281XBladePtr<16, blade4Pin, Color8::GRB, PowerPINS<bladePowerPin1> >()),
SubBladeWithStride(1, 15, 2, NULL),
WS281XBladePtr<3, blade6Pin, Color8::GRB, PowerPINS<bladePowerPin4> >()
CONFIGARRAY(no_blade_presets), "nbsave" }
,
};
#endif
#ifdef CONFIG_BUTTONS
Button PowerButton(BUTTON_POWER, powerButtonPin, "pow");
Button AuxButton(BUTTON_AUX, auxPin, "aux");
#endif
/* Generated with Fett263 Config Helper v3.07 */
Current Arduino Error:
In file included from C:\Users\Marc\Desktop\ProffieOS\ProffieOS\ProffieOS.ino:621:
C:\Users\Marc\Desktop\ProffieOS\ProffieOS\config\myconfig.h:348:17: error: expected initializer before 'presets'
348 | Preset no_blade presets[] = {
| ^~~~~~~
In file included from C:\Users\Marc\Desktop\ProffieOS\ProffieOS\ProffieOS.ino:591:
C:\Users\Marc\Desktop\ProffieOS\ProffieOS\config\myconfig.h:475:21: error: expected '}' before 'no_blade_presets'
475 | CONFIGARRAY(no_blade_presets), "nbsave" }
| ^~~~~~~~~~~~~~~~
C:\Users\Marc\Desktop\ProffieOS\ProffieOS\common\preset.h:6:24: note: in definition of macro 'CONFIGARRAY'
6 | #define CONFIGARRAY(X) X, NELEM(X)
| ^
In file included from C:\Users\Marc\Desktop\ProffieOS\ProffieOS\ProffieOS.ino:621:
C:\Users\Marc\Desktop\ProffieOS\ProffieOS\config\myconfig.h:468:2: note: to match this '{'
468 | { NO_BLADE, WS281XBladePtr<10, bladePin, Color8::GRB, PowerPINS<bladePowerPin2, bladePowerPin3> >(),
| ^
In file included from C:\Users\Marc\Desktop\ProffieOS\ProffieOS\ProffieOS.ino:591:
C:\Users\Marc\Desktop\ProffieOS\ProffieOS\config\myconfig.h:475:21: error: expected '}' before 'no_blade_presets'
475 | CONFIGARRAY(no_blade_presets), "nbsave" }
| ^~~~~~~~~~~~~~~~
C:\Users\Marc\Desktop\ProffieOS\ProffieOS\common\preset.h:6:24: note: in definition of macro 'CONFIGARRAY'
6 | #define CONFIGARRAY(X) X, NELEM(X)
| ^
In file included from C:\Users\Marc\Desktop\ProffieOS\ProffieOS\ProffieOS.ino:621:
C:\Users\Marc\Desktop\ProffieOS\ProffieOS\config\myconfig.h:459:24: note: to match this '{'
459 | BladeConfig blades[] = {
| ^
In file included from C:\Users\Marc\Desktop\ProffieOS\ProffieOS\ProffieOS.ino:591:
C:\Users\Marc\Desktop\ProffieOS\ProffieOS\config\myconfig.h:475:21: error: expected ',' or ';' before 'no_blade_presets'
475 | CONFIGARRAY(no_blade_presets), "nbsave" }
| ^~~~~~~~~~~~~~~~
C:\Users\Marc\Desktop\ProffieOS\ProffieOS\common\preset.h:6:24: note: in definition of macro 'CONFIGARRAY'
6 | #define CONFIGARRAY(X) X, NELEM(X)
| ^
In file included from C:\Users\Marc\Desktop\ProffieOS\ProffieOS\ProffieOS.ino:621:
C:\Users\Marc\Desktop\ProffieOS\ProffieOS\config\myconfig.h:475:49: error: expected declaration before '}' token
475 | CONFIGARRAY(no_blade_presets), "nbsave" }
| ^
C:\Users\Marc\Desktop\ProffieOS\ProffieOS\config\myconfig.h:477:1: error: expected unqualified-id before ',' token
477 | ,
| ^
C:\Users\Marc\Desktop\ProffieOS\ProffieOS\config\myconfig.h:478:1: error: expected unqualified-id before '}' token
478 | };
| ^
C:\Users\Marc\Desktop\ProffieOS\ProffieOS\config\myconfig.h:478:1: error: expected declaration before '}' token
exit status 1
Compilation error: expected initializer before 'presets'
